85 mm Thickness Office Movable Sound Proof Conference Room Acoustic Partition Walls
The details of sound proof partitions
Model: BG65,BG85,BG100 Sound Proof Partition Wall
Sound proof partition wall thickness: 65mm~2.56inch, 85mm~3.35inch, 100mm~3.9inch
Board thickness: 9mm or 12mm
Blinds thickness: 16mm,25mm
Partition-wall standard length: ANY
Partition-wall standard height: 2000—13000mm, 78.7inch ~ 512inch
Optional material: Fabric/Melamine board/Glass/metal board/Aluminum Composite Panel/Soft panel/Blinds/Wooden board
Description partition wall / folding door / movable wall /
Characteristic: Movable / Stable Structure/ Sound insulation / Pro-environment/ fireproofing / Stylish
Product dominant: Design systematization / Industrialization productions / Standardization Installation / Diversification working / Modernization appearance
Service: Supply consulting service, CAD project, office layout design /Work environment consulting /Products instruction
Sales Countries: Made in china. Sales all over the world.
How to install the partition walls
1. After the sound proof partitions rail is transported to the construction site, the construction personnel should first understand the general decoration style of the site, including the ceiling shape, the ground shape, whether there is a skirt line on the wall, etc., timely communicate with the on-site woodworker, and then release the line to determine the track installation. position;
2. After the horizontal line is placed, the construction side will determine the layout direction of the air-conditioning duct fire-fighting pipe, and it is convenient to determine the steel structure installation form, whether it is a straight pull or a diagonal support or a U-slot fix. These are responsible installation teams. Do the preparation before the construction, otherwise work and do things, when the impact on the site construction layout, but also to rework, seriously affect the construction progress, will also bring unnecessary trouble to Party A;
3. After the track is installed, the track level will be self-checked again, and finally the steel structure will be rust-proofed, and then Party A will be notified and the position of the track movable port will be clearly stated. When the ceiling is clearly indicated, it cannot be fixed with the track. Otherwise, loading and unloading The door panel will likely damage the integrity of the ceiling.
| Panel Suspension: | Top hunge system without the need for a floor track. |
| Panel Width: | Each panel 600mm-1200mm. |
| Track: | Aluminum OR Steel Track |
| Rollor on panel | Single or double roller |
| Panel Frames: | Heavy-duty steel-gusseted aluminum inner frames reinforced with full height. |
| Top&bottm seals: | Top and bottom pressure retractable seals ensure effortless moved and locked. |
| Module: | 700mm - 1200mm maximum. |
| Panel stacking: | Numerous panel stacking options for complete flexibility. |
| Panel face: | MDF,Plywood,woven fabric.Leather,Natural wood veneer, Melamine,Wood moldings, etc |
| Finishes: | Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard. |
About us
The BUNGE company has a strong technical installation team and marketing team. The factory has introduced advanced foreign production technology, based on the advanced American partition technology, absorbs the essence of German and Danish partition technology, and continuously optimizes, improves and innovates to ensure products. It has excellent sound-absorbing and sound-absorbing effects, fire-retardant and flame-retardant properties, and at the same time absorbs professional technical talents. Through continuous innovation of technology, the products have better sound insulation effect and more flexible moving space function. There are 8 types of Ruizhuang movable partitions: 65 type, 85 type, 100 type, 125 ultra ultra high type and 65 type frameless glass, 85 type framed glass screen, and 32 type folding screen, among which the ultra high type movable partition With superior technical level, it adopts super-strong rails, imported hanging wheels, special-made barges and automatic steering system, with a height of up to 18m and a sound insulation coefficient of 55db. It is suitable for large-scale high-grade conference halls, banquet halls, exhibition halls. Exhibition halls and other professional venues.
